Features:All using 105°C long life electrolytic capacitorsProtections: Short circuit / Overload / Over voltageMeet EMS EN50082-2/EN61000-6-2heavy industry level (35~150W)Withstand 300VAC surge input for 5 sec.High operating temperature up to 70°CWithstand 5G vibration testMiniature size, high power densityHigh efficiency, long life and high reliabilityLED indicator for power on100% full load burn-in testSuitable for critical applications3 years warrantyGeneral Specification (Please refer to images below for detailed datasheet)AC input voltage range:88~264VAC, 125~373VDCAC inrush current (max.):40A at 230VACDC adjustment range:±10% by potentiometer for single output; CH1 -5%~+10% by potentiometer for multiple outputOverload protection:110%~150% hiccup mode, auto-recoveryOver voltage protection:115%~135% rated output voltage, hiccup mode, auto-recoveryWithstand voltage:I/P - O/P: 3kVAC, I/P - FG: 1.5kVAC, O/P - FG: 0.5kVAC, 1 minuteWorking temperature:-25~+70°C (refer to the derating curve for different models)Vibration:10~500Hz, 5G 10min. /1 cycle, period for 60 min. each along X, Y, Z axesSafety standards:UL60950-1, TUV EN60950-1 approvedEMC standards:EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2) (35~150W)Connection:Terminal block for input and outputDimension (LxWxH):199x 98x 38Case No.:902APacking:20pcs /15kg
